i Series: The Rugged Industrial Thin Client Built to Last
Introducing the TCD I SERIES Industrial Thin Client:
Engineered for durability and performance, our industrial-grade aluminum shell and fanless design ensure optimal cooling, even in the most extreme temperature and humidity conditions. Powered by an Intel Celeron quad-core processor, the TCD i Series industrial thin client fuels your productivity effortlessly.
Tough and resilient, this product is built to withstand the rigors of demanding environments while delivering exceptional performance.
WHEN THE CONDITIONS GET HARSH!
Tough Industrial Design
Rugged Metal Casing perfect for industrial and manufacturing environments withstanding warmer and more humid conditions.
Dual display and 4K resolution rate
2 HDMI ports allowing the unit to support 2 screens at a full 4k resolution with 60 Hz refresh rate.
Smooth Video and Communication
Ability to handle apps like Microsoft Teams with ease.
Support Multiple VDI protocols
Citrix ICA/HDX, VMware PCoIP, Microsoft RDP, Microsoft AVD, Windows 365, Frame, and others.
Upgradable Components
Memory (RAM) and SSD are not soldered and can be upgraded.
Connectivity.
Specification.
Audio1 x Audio (Mic/Speaker)
| Processor | Intel quad-core 2.0Ghz, max turbo 2.6Ghz (J6412) |
| Available Operating System | Linux-based OS, or Win 11 IoT |
| Protocols | Citrix ICA/HDX, Omnissa Blast Extreme, PCoIP, Microsoft RDP, AVD |
| RAM (DDR4) | 8GB |
| Storage (mSATA) | 128GB |
| Display | HDMI x 2 |
| Resolution | HDMI: 4096 x 2160 @60Hz, Synchronous and Asynchronous |
| Color Depth | 32-bit |
| LAN | x 1 (10/100/1000Mbps, RJ-45) |
| USB 2.0 | x 2 (front) & x 2 (rear) |
| USB 3.0 | x 4 (front) |
| COM Port | x 1 |
| Dimension | 150mm x 126.5mm x 45mm |
| Net Weight | 0.84 kg |
| Adapter | DC 12V Input |
| Power Consumption | < 10w |
| Security | Standard Kensington anti-theft keyhole |
| Cooling | Fan-less Convection |
| Operation Temperature | 0°C to 40°C (Commercial HDD), -20°C to 60°C (Industrial SSD) |
| Relative Humidity | 0% to 95% non-condensing |
Optional items.
| RAM (DDR4) | 4 GB, 8 GB, or 16 GB Options |
| Storage | 32 GB, 64 GB, 128GB, 256 GB Options |
| m.2 Slot | x 1 SATA, x 1 Mini PCIE Slot, x 1 Wi-Fi or 4G |
| Wi-Fi | x 1 |
| TPM Module | Optional |
| Mountings | VESA mounting bracket |
